Lawn Tractors > John Deere > X724

John Deere X724



John Deere X724 lawn tractor photo
2006 - 2012
Select X700 Series
Garden tractor
Series map:
X720
X724
X728
27.0hp
27.0hp
27.0hp
Production
ManufacturerJohn Deere
Garden tractor
Built in Horicon, Wisconsin, USA
Original price was $9,729 in 2011
Variants
X720two-wheel drive
X7242WD, all-wheel steer
X728four-wheel drive
X7294WD, all-wheel steer
John Deere X724 Engine
27HP Kawasaki 745cc 2-cyl gasoline
Fuel tank6.5 gal (2006-2010)
24.6 L
 5.2 gal (2011-)
19.7 L
Engine details ...
John Deere X724 Transmission
hydrostatic
Transmission details ...
Mechanical
Two-wheel drive
Steeringfour-wheel hydrostatic power
Wet disc brakes
Open operator station featuring 18-inch seat with 7-inches of adjustment. Cupholder, toolbox, tilt steering, and 12-volt outlet standard. Optional soft-side or hard cab.
Photos
John Deere X724 Ultimate, right side.
John Deere X724 photos...
Hydraulics
Pressure924 psi
63.7 bar
Valves2
Total flow4.5 gpm
17.0 lpm
Tractor hitch
Rear Type0 (optional)
 1-Limited (optional)
Power Take-off (PTO)
Rear PTOindependent (optional)
Rear RPM540
Mid PTOindependent
Mid RPM2000
Front PTOoptional
Front RPM2000
Dimensions & Tires
Wheelbase54.5 inches
138 cm
Weight915 lbs
415 kg
Front tire18x7.00-8
Rear tire26x10.50-12
Full dimensions and tires ...
John Deere X724 attachments
48" mid-mount mower deck
54" mid-mount mower deck
62" mid-mount mower deck
Attachment details ...
X724 Serial Numbers
2006010001
2007020001
2008030001
2009040001
2010050001
2011060001

FAQ: How to read a serial number table.
X724 Serial Location
John Deere X724 serial number location
On the center-right of main tractor frame, just behind hydraulic couplers.
Electrical
Groundnegative
Charging systemalternator
Charging amps20
 40 (optional)
Battery CCA340
Battery volts12
References
X724 references literature
Select Series Tractors published in 2007, by John Deere
Select Series Tractors published in 2009, by John Deere
Select Series Tractors published in 2012, by John Deere
Commercial & Consumer Equipment Purchasing Guide published in 2007, by John Deere
Riding Lawn Equipment Attachments & Accessories published in 2011, by John Deere
