J.I. Case 750
|
|
| Production | |
| Manufacturer | J.I. Case |
| Industrial Crawler tractor | |
| J.I. Case 750 Engine | |
| J.I. Case 4.9L 4-cyl diesel | |
 Engine details ... |
| J.I. Case 750 Transmission | |
| 4-speed torque converter | |
 Transmission details ... |
| J.I. Case 750 Power | |
| Engine (gross) | 72 hp 53.7 kW |
| Engine (net) | 63 hp 47.0 kW |
| Mechanical | |
| Drive | crawler |
| Hydraulic disc brakes | |
| Open operator station. | |
| Photos | |
| No photos of the J.I. Case 750 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Capacity | |
| Fuel | 36 gal 136.3 L |
| Hydraulic system | 14 gal 53.0 L |
| Hydraulics | |
| Capacity | 14 gal 53.0 L |
| Pressure | 1250 psi 86.2 bar |
| Pump flow | 25 gpm 94.6 lpm |
| Dimensions & Tracks | |
| Weight | 13900 lbs 6305 kg |
| 14-inch tracks | |
 Full dimensions and tracks ... | |
| References | |
 | |
| Model 750 Industrial Tilt Dozer published in 1960, by J.I. Case | |
| Industrial Tractors and Equipment published in 1965, by J.I. Case |
