International Harvester 2510B


International Harvester 2510B industrial tractor photo
1974 - 1977
Industrial tractor
Production
Manufacturer:International Harvester
Type:Industrial tractor
Variants
2500B:utility tractor
2505B:utility loader
2510B:Pay loader
2514B:loader-backhoe
International Harvester 2510B Power
Engine (gross):80 hp
59.7 kW
Engine (net):70 hp
52.2 kW
Gas hydro Drawbar (claimed):39 hp
29.1 kW
Gas gear Drawbar (claimed):45 hp
33.6 kW
Diesel hydro Drawbar (claimed):42 hp
31.3 kW
Diesel gear Drawbar (claimed):45 hp
33.6 kW
Gas hydro PTO (claimed):50 hp
37.3 kW
Gas gear PTO (claimed):52 hp
38.8 kW
Diesel hydro PTO (claimed):53 hp
39.5 kW
Diesel gear PTO (claimed):52 hp
38.8 kW
International Harvester 2510B Engines
International Harvester 3.9L 4-cyl diesel
International Harvester 3.3L 4-cyl gasoline
Fuel tank:20 gal
75.7 L
Engine details ...
Mechanical
Chassis:4x2 2WD
Steering:power
Brakes:independent hydraulic wet disc
Cab:Open operator station. Four-post ROPS available.
Transmissions:8-speed gear
 8-speed reverser
Transmission details ...
Hydraulics
Type:open center
Pressure:2500 psi
172.4 bar
Pump flow:12 gpm
45.4 lpm (main)
 4 gpm
15.1 lpm (transmission pump)
 18 gpm
68.1 lpm (loader pump)
Tractor hitch
Rear Type:II
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:540
Dimensions & Tires
Wheelbase:84 inches
213 cm
Front tire:7.50-16
Rear tire:14.9-24
Full dimensions and tires ...
Electrical
Ground:negative
Charging system:alternator
Charging amps:37
Battery
Volts:12
