Tractors > International Harvester > 2400A
      -Brand search:


    International Harvester 2400A

    No photo available
    Industrial tractor






    Production:

    Manufacturer:International Harvester


    Variants:

    2400A Lo-Boy:low center of gravity


    International Harvester 2400A Engines:

       International Harvester 2.9L 3-cyl diesel
       International Harvester 2.6L 4-cyl gasoline
    full engine details ...


    Capacity:

    Fuel:18.5 gal [70.0 L]


    3-Point Hitch:

    Rear Type:1


    Power Take-off (PTO):

    Rear PTO:independent
    Rear RPM:540/1000
    Mid PTO:optional
    Mid RPM:1000


    Dimensions & Tires:

    Wheelbase:75 inches [190 cm] (Lo-Boy)
     82 inches [208 cm]
    Weight:4000 to 4140 pounds
    full dimensions and tires ...


    2400A Serial Numbers:


    - Serial numbers unknown -



    International Harvester 2400A Power:

    Engine:46 hp [34.3 kW]
    Drawbar (claimed):35 hp [26.1 kW]
    PTO (claimed):40 hp [29.8 kW]


    Mechanical:

    Chassis:4x2 2WD
    Steering:hydrostatic power
    Brakes:independent hydraulic disc
    Steering flow:12 gpm [45.4 lpm]
    Steering press.:2300 psi [158.6 bar]


    Electrical:

    Charging system:32


    Battery:

    Number:1 (gas)
     2 (diesel)
    Volts:12 (gas)
     6 (diesel)
    Amp-hours:40 (gas)
     135 (diesel)
