J.I. Case 520
|
|
| Production | |
| Manufacturer | J.I. Case |
| Industrial tractor | |
| Total built | 265 |
| Variants | |
| 500 | farm tractor |
| J.I. Case 520 Engine | |
| J.I. Case 6.2L 6-cyl diesel | |
 Engine details ... |
| J.I. Case 520 Transmission | |
| 4-speed gear | |
 Transmission details ... |
| J.I. Case 520 Power |
| Mechanical | |
| Two-wheel drive | |
| Final drives | roller chain |
| Steering | manual |
| Steering | power OptOptional |
| Disc brakes | |
| Open operator station. | |
| Photos | |
| No photos of the J.I. Case 520 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Capacity | |
| Fuel | 30 gal 113.6 L |
| Hydraulic system | 3.5 gal 13.2 L |
| Hydraulics | |
| Type | open center |
| Capacity | 3.5 gal 13.2 L |
| Pressure | 1030 psi 71.0 bar |
| Pump flow | 20 gpm 75.7 lpm |
| Power Take-off (PTO) | |
| Rear PTO | independent OptOptional |
| Clutch | wet disc |
| Rear PTO Type | 540 (1.375) |
| Engine RPM | 540@1350 |
| Dimensions & Tires | |
| Wheelbase | 87.5 inches 222 cm |
| Weight | 7688 lbs 3487 kg |
| Front tire | 9x15 |
| Rear tire | 18x26 |
 Full dimensions and tires ... | |
| 520 Serial Numbers | |
| Location: | Serial number plate on the right side of the battery support. |
| Electrical | |
| Ground | negative |
| Charging system | generator |
| Batteries | 2 |
| Battery volts | 6 |
| Battery AH | 200 |
| References | |
 | |
| Operator's Instruction Manual Industrial Diesel Tractor Model 520 (5682) published in 1957 |
