Tractors > Ford > 445C

Ford 445C

Ford 445C industrial tractor photo
1988 - 1992   C Series
Industrial tractor
Previous model:Ford 445A
Next model:Ford 445D
Series next:Ford 545C
Series back:Ford 345C






Production:

Manufacturer:Ford


Ford 445C Engine:

   Ford 3.1L 3-cyl diesel
full engine details ...


Capacity:

Fuel:16 gal [60.6 L]
Hydraulic system:8.7 gal [32.9 L] (loader)
Steering:4 qts [3.8 L]


3-Point Hitch:

Rear Type:I
Control:position control and top-link draft sensing
Rear lift:3080 lbs [1397 kg]


Power Take-off (PTO):

Rear PTO:independent
Rear RPM:540 (1.375)
Engine RPM:540@1800


Dimensions & Tires:

Wheelbase:81 inches [205 cm]
Weight:8610 to 8830 pounds
Front tire:7.50-16
Rear tire:16.9-24
full dimensions and tires ...


Ford 445C attachments:

 front-end loader
 backhoe
all 445C attachments ...


445C Serial Numbers:


- Serial numbers unknown -



Ford 445C Power:

Engine (gross):56 hp [41.8 kW]
Engine (net):52 hp [38.8 kW]
PTO (claimed):46.7 hp [34.8 kW]


Mechanical:

Chassis:4x2 2WD
Steering:power
Brakes:wet disc
Cab:Two-post ROPS with available canopy. Four-post ROPS/FOPS optional.


Hydraulics:

Type:open center
Capacity:8.7 gal [32.9 L] (loader)
Pressure:2450 psi [168.9 bar]
Pump flow:5.6 gpm [21.2 lpm] (hitch)
 8.5 gpm [32.2 lpm] (hitch optional)
 26 gpm [98.4 lpm] (loader pump)
Steering flow:5.9 gpm [22.3 lpm]
Steering cap.:4 qts [3.8 L]


Electrical:

Ground:negative
Charging system:alternator
Charging amps:55


Battery:

Number:1
Cold-cranking amps:750
Volts:12
Amp-hours:128
