John Deere 210LJ
|
|
| Production | |
| Manufacturer | John Deere |
| Industrial tractor | |
| John Deere 210LJ Engine | |
| John Deere 4.5L 4-cyl diesel | |
 Engine details ... |
| John Deere 210LJ Transmission | |
| 4-speed full power shift | |
 Transmission details ... |
| John Deere 210LJ Power | |
| Engine | 84 hp 62.6 kW |
| PTO (claimed) | 55 hp 41.0 kW |
| Mechanical | |
| Four-wheel drive | |
| Final drives | outboard planetary |
| Hydraulic wet disc brakes | |
| Two-post canopy ROPS/FOPS. Cab optional. | |
| Photos | |
| No photos of the John Deere 210LJ are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Capacity | |
| Fuel | 27 gal 102.2 L |
| Hydraulic system | 16.3 gal 61.7 L |
| 20 gal (with PTO) 75.7 L | |
| Hydraulics | |
| Type | open center |
| Capacity | 16.3 gal 61.7 L |
| 20 gal (with PTO) 75.7 L | |
| Pressure | 2750 psi 189.6 bar |
| Valves | 4 to 5 |
| Total flow | 25.3 gpm 95.8 lpm |
| Tractor hitch | |
| Rear Type | II OptOptional |
| Power Take-off (PTO) | |
| Rear PTO | continuous OptOptional |
| Rear PTO Type | 540 |
| Dimensions & Tires | |
| Weight | 14510 lbs 6581 kg |
| Front tire | 12-16.5 |
| Rear tire | 16.9-24 |
 Full dimensions and tires ... | |
| John Deere 210LJ attachments | |
| front-end loader | |
 Attachment details ... |
| Electrical | |
| Charging system | alternator |
| ROPS Charging amps | 70 |
| Cab Charging amps | 90 |
| Batteries | 1 |
| 2 (optional) | |
| Battery volts | 12 |
| References | |
 | |
| LJ Loaders published in 2008, by John Deere |
