CaseIH Luxxum 100


CaseIH Luxxum 100 tractor photo
2016 - 2023
Model year
Luxxum Series
Utility tractor
Series:Luxxum 100Luxxum 110
Production
Manufacturer:CaseIH
Type:Utility tractor
Factory:Saint Valentin, Austria
CaseIH Luxxum 100 Power
Engine (gross):99 hp
73.8 kW
CaseIH Luxxum 100 Engine
FPT 3.4L 4-cyl diesel
Fuel tank:39.6 gal
149.9 L
Exhaust fluid (DEF):3.7 gal
14.0 L
Engine details ...
Mechanical
Chassis:4x4 MFWD 4WD
Differential lock:electro-hydraulic front and rear
Steering:power
Brakes:wet disc
Cab:Cab standard with air-conditioning.
Transmission:32-speed four-speed power shift
Transmission details ...
Photos
No photos of the CaseIH Luxxum 100 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Type:closed center load sensing
Rear valves:4*Optional
Mid valves:2*Optional
Pump flow:21.1 gpm
79.9 lpm
 26.4 gpm
99.9 lpm *Optional
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:540/540E/1000/1000E
Front PTO:independent
Front RPM:540/540E/1000/1000E
Dimensions & Tires
Wheelbase:95.3 inches
242 cm
 95.7 inches
243 cm (suspended axle)
Weight:9678 lbs
4389 kg
Front tire:480/65R24
Rear tire:540/65R38
Full dimensions and tires ...
Electrical
Charging system:alternator
