CaseIH Farmall 120U
|
|
| Production | |
| Manufacturer | CaseIH |
| Utility tractor | |
| CaseIH Farmall 120U Engine | |
| FPT 3.4L 4-cyl diesel | |
| Fuel tank | 43.6 gal 165.0 L |
| Exhaust fluid (DEF) | 3.2 gal 12.1 L |
 Engine details ... | |
| CaseIH Farmall 120U Transmissions | |
| 16-speed 4-speed power shift | |
| 16-speed | |
| 32-speed creeper | |
 Transmission details ... |
| CaseIH Farmall 120U Power | |
| Engine | 117 hp 87.2 kW |
| PTO (claimed) | 100 hp 74.6 kW |
| Drawbar (tested) | 76.2 hp 56.8 kW |
| PTO (tested) | 104.6 hp 78.0 kW |
 Performance test details ... | |
| Mechanical | |
| Four-wheel drive | |
| Final drives | inboard planetary |
| Power steering | |
| Wet disc brakes | |
| Cab standard with air-conditioning. | |
| Photos | |
| No photos of the CaseIH Farmall 120U are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | open center |
| Rear valves | 2 or 3 |
| Pump flow | 21.1 gpm 79.9 lpm |
| Tractor hitch | |
| Rear Type | II |
| Control | electronic draft control |
| Rear lift (at 24"/610mm) | 8809 lbs 3995 kg |
| Drawbar | Cat. 2 |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540/1000 |
| Dimensions & Tires | |
| Wheelbase | 93.7 inches 237 cm |
| Weight | 10031 lbs 4550 kg |
| Front tire | 14.9R24 |
| Rear tire | 460/85R34 |
 Full dimensions and tires ... | |
| CaseIH Farmall 120U attachments | |
| front-end loader | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 120 |
| Battery volts | 12 |
| References | |
 | |
| Utility Farmall U Series Tractors published in 2018, by CaseIH | |
| Farmall Utility Series Tractors published in 2021, by CaseIH |
