Valtra S292


Valtra S292 tractor photo
2008 - 2011
S Series
Row-Crop tractor
S280
Series:S262S292S322
S293
Production
Manufacturer:Valtra (a part of AGCO)
Type:Row-Crop tractor
Valtra S292 Power
Engine:286 hp
213.3 kW
Valtra S292 Engine
SisuDiesel 8.4L 6-cyl diesel
Fuel tank:155.9 gal
590.1 L
Exhaust fluid (DEF):7.9 gal
29.9 L
Engine details ...
Mechanical
Chassis:4x4 MFWD 4WD
Steering:power
Brakes:hydraulic wet disc
Cab:Cab standard with air-conditioning.
Transmission:continuously-variable transmission
Transmission details ...
Photos
No photos of the Valtra S292 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Type:closed center load sensing
Rear valves:4 to 6
Front valves:0 to 2
Pump flow:52.8 gpm
199.8 lpm
Tractor hitch
Rear Type:IV/III
Rear lift:26455 lbs
11999 kg
Front lift:11023 lbs
5000 kg
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:540E/1000E/1000 (1.375)
Engine RPM:540E@1589
1000E@1589
1000@2031
Dimensions & Tires
Wheelbase:122.2 inches
310 cm
Weight:22708 lbs
10300 kg
Front tire:620/65R34
Rear tire:710/75R42
Full dimensions and tires ...
Electrical
Ground:negative
Charging system:alternator
Battery volts:12
