Valtra N174


No photo available
2015 - 2020
N Series
Row-Crop tractor
Series:N154N174
N175
Production
Manufacturer:Valtra (a part of AGCO)
Type:Row-Crop tractor
Valtra N174 Power
Engine:162.3 hp
121.0 kW
Valtra N174 Engine
AGCO Power 4.9L 4-cyl diesel
Fuel tank:62.1 gal
235.0 L
 83.2 gal
314.9 L *Optional
 42.3 gal
160.1 L (steel tank)
Exhaust fluid (DEF):11.9 gal
45.0 L
Engine details ...
Mechanical
Chassis:4x4 MFWD 4WD
Steering:power
Brakes:wet disc
Cab:Cab standard with air-conditioning.
Transmissions:30-speed five-speed power shift
 continuously-variable transmission
Transmission details ...
Photos
No photos of the Valtra N174 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Type:open center
 closed center*Optional
Rear valves:2 to 5
Pump flow:19.3 gpm
73.1 lpm (open)
 23.8 gpm
90.1 lpm (open option)
 30.4 gpm
115.1 lpm (closed)
 42.3 gpm
160.1 lpm (closed option)
 52.8 gpm
199.8 lpm (closed option)
Tractor hitch
Rear lift:17534 lbs
7953 kg
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:540/1000
Front PTO:independent*Optional
Front RPM:1000
Dimensions & Tires
Wheelbase:104.9 inches
266 cm
Weight:13889 lbs
6300 kg
Full dimensions and tires ...
Electrical
Ground:negative
Charging system:alternator
Battery volts:12
