Valtra A74


Valtra A74 tractor photo
2017 - 2020
A Series
Utility tractor
Series:A74A84
A75
Production
Manufacturer:Valtra (a part of AGCO)
Type:Utility tractor
Valtra A74 Power
Engine:72 hp
53.7 kW
Valtra A74 Engine
AGCO Power 3.3L 3-cyl diesel
Fuel tank:39.6 gal
149.9 L
Engine details ...
Mechanical
Chassis:4x4 MFWD 4WD
Steering:power
Brakes:wet disc
Cab:Cab standard with available air-conditioning.
Transmissions:12-speed power shuttle
 24-speed creeper
Transmission details ...
Photos
No photos of the Valtra A74 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Type:open center
Pump flow:17.2 gpm
65.1 lpm
Power Take-off (PTO)
Rear PTO:independent
Clutch:electro-hydraulic
Rear RPM:540/540E
Engine RPM:540@1920
540E@1560
Dimensions & Tires
Wheelbase:88.6 inches
225 cm
Weight:7716 lbs
3499 kg
Full dimensions and tires ...
Electrical
Ground:negative
Battery volts:12
