Fendt 1156 Vario MT
| | 2020 - |
| 1100 Vario MT Series | | Agricultural Crawler tractor |
|
| Production |
| Manufacturer: | Fendt (a part of AGCO)
|
| Type: | Agricultural Crawler tractor
|
| Fendt 1156 Vario MT Power |
| Engine (gross): | 556.5 hp
415.0 kW
|
| Mechanical |
| Chassis: | crawler
|
| Cab: | Cab standard with air-conditioning.
|
| Transmission: | continuously-variable transmission
|
 Transmission details ... |
| Photos |
| No photos of the Fendt 1156 Vario MT are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Type: | closed center pressure-flow compensated
|
| Pressure: | 2900 psi
200.0 bar
|
| Rear valves: | 4 to 8
|
| Pump flow: | 58.1 gpm
219.9 lpm
|
| | 116.2 gpm
439.8 lpm *Optional
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 1000/1000E
|
| Electrical |
| Ground: | negative
|
| Charging system: | alternator
|
| Charging amps: | 325
|
| Batteries: | 3
|
| Battery volts: | 12
|
| Page information |
| Last update: | December 23, 2020
|
| Copyright: | Copyright 2020 TractorData LLC
|
| Contact: | Peter@TractorData.com
|
©2000-2020 - TractorData™. Notice: Every attempt is made to ensure the data listed
is accurate. However, differences between sources, incomplete listings,
errors, and data entry mistakes do occur.
Consult official
literature from the manufacturer before attempting any service or repair.
Engine details ...
Full dimensions and tracks ...
