Fendt 412 Vario


Fendt 412 Vario tractor photo
2006 - 2012
400 Vario Series
Row-Crop tractor
Farmer 411 Vario
Series:411 Vario412 Vario413 Vario
Production
Manufacturer:Fendt (a part of AGCO)
Type:Row-Crop tractor
Fendt 412 Vario Power
Engine (gross):122 hp
91.0 kW
Engine (net):108.6 hp
81.0 kW
Engine (max):128.7 hp
96.0 kW
Fendt 412 Vario Engine
Deutz 4.0L 4-cyl diesel
Fuel tank:64.7 gal
244.9 L
Engine details ...
Mechanical
Chassis:4x4 MFWD 4WD
Steering:power
Brakes:wet disc
Cab:Cab standard with heat. Air-conditioning optional.
Transmission:continuously variable transmission
Transmission details ...
Photos
No photos of the Fendt 412 Vario are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Type:load sensing
Pressure:2900 psi
200.0 bar
Pump flow:19.8 gpm
74.9 lpm
 29.1 gpm
110.1 lpm *Optional
Tractor hitch
Rear Type:III/II
Rear lift:16424 lbs
7449 kg
Front lift:6834 lbs
3099 kg
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:540/540E/1000
Front PTO:independent*Optional
Front RPM:540
 1000
Dimensions & Tires
Wheelbase:95.2 inches
241 cm
Weight:11905 lbs
5400 kg
Front tire:480/65R24
Rear tire:540/65R38
Full dimensions and tires ...
Electrical
Ground:negative
Charging system:alternator
Charging amps:150
Charging volts:14
Battery volts:12
Battery AH:90
