Massey Ferguson 8S.245


Massey Ferguson 8S.245 tractor photo
2020 -
8S Series
Row-Crop tractor
Series map:
8S.225
8S.245
8S.265
165.0kw
180.0kw
195.0kw
Production
ManufacturerMassey Ferguson (a part of AGCO)
Row-Crop tractor
Massey Ferguson 8S.245 Engine
AGCO Power 7.4L 6-cyl diesel
Fuel tank121.5 gal
459.9 L
 132 gal (Dyna-VT)
499.6 L
Exhaust fluid (DEF)11.4 gal
43.1 L
Engine details ...
Massey Ferguson 8S.245 Transmissions
28-speed
continuously-variable transmission
Transmission details ...
Massey Ferguson 8S.245 Power
Engine241.4 hp
180.0 kW
PTO (claimed)213.2 hp
159.0 kW
Mechanical
Four-wheel drive
Differential lockautomatic front and rear
Power steering
Trailer brakespneumatic
 hydraulic OptOptional
Cab standard with air-conditioning.
Photos
No photos of the Massey Ferguson 8S.245 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeclosed center load-sensing
Pressure2901 psi
200.0 bar
Rear valves5 OptOptional
Front valves2 OptOptional
Pump flow39.6 gpm
149.9 lpm
 54.2 gpmOptOptional
205.1 lpm
Tractor hitch
Rear TypeIII
Controlposition and draft control
Rear lift (at ends)22046 lbs
10000 kg
Front lift10582 lbs
4799 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540/1000 (1.375)
 1000 (1.75)
Engine RPM540@1867
540E@1499
1000@1903
1000E@1528
Front PTOindependent
Front PTO Type1000
Engine RPM1000@1920
Dimensions & Tires
Wheelbase120.1 inches
305 cm
Weight19180 to 22046 pounds
Front tire540/65R30
Rear tire650/65R42
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Battery volts12
References
8S.245 references literature
MF 8S published in 2020, by Massey Ferguson
MF 8S published in 2022, by Massey Ferguson
MF 8S Series published in 2023, by Massey Ferguson
