Deutz-Fahr 4090E
|
|
| Production | |
| Manufacturer | Deutz-Fahr |
| Utility tractor | |
| Deutz-Fahr 4090E Engine | |
| SDF 2.9L 3-cyl diesel | |
| Fuel tank | 19.8 gal 74.9 L |
 Engine details ... | |
| Deutz-Fahr 4090E Transmissions | |
| 15-speed partially synchronized | |
| 8-speed partially synchronized | |
 Transmission details ... |
| Deutz-Fahr 4090E Power | |
| Engine (gross) | 82.6 hp 61.6 kW |
| Engine (max) | 87.2 hp 65.0 kW |
| Mechanical | |
| Four-wheel drive | |
| Differential lock | electro-hydraulic |
| Power steering | |
| Wet disc brakes | |
| Two-post folding ROPS. | |
| Photos | |
| No photos of the Deutz-Fahr 4090E are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | open center |
| Valves | 1 to 3 |
| Pump flow | 13.2 gpm 50.0 lpm |
| Tractor hitch | |
| Rear Type | II |
| Control | position and draft control |
| Rear lift | 5512 lbs 2500 kg |
| 7717 lbsOptOptional 3500 kg | |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540 |
| 540/540E OptOptional | |
| 540/540E/1000 OptOptional | |
| Dimensions & Tires | |
| Wheelbase | 82.7 inches 210 cm |
| Weight | 6614 lbs 3000 kg |
| Front tire | 360/70R20 |
| Rear tire | 420/70R30 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| References | |
 | |
| 4E Series published in 2018, by Deutz-Fahr |
