Yanmar EF334V
|
|
| Production | |
| Manufacturer | Yanmar |
| Compact Utility tractor | |
| Yanmar EF334V Engine | |
| Yanmar 1.6L 3-cyl diesel | |
| Fuel tank | 9.5 gal 36.0 L |
 Engine details ... | |
| Yanmar EF334V Transmission | |
| 16-speed four-speed power shift | |
 Transmission details ... |
| Yanmar EF334V Power | |
| Engine | 33.5 hp 25.0 kW |
| Mechanical | |
| Four-wheel drive |
| Photos | |
| No photos of the Yanmar EF334V are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Tractor hitch | |
| Rear Type | JIS1 |
| Rear lift | 3307 lbs 1500 kg |
| Power Take-off (PTO) | |
| Rear PTO | 540 (1.375) |
| Engine RPM | 555@2700 |
| 784@2700 | |
| 991@2700 | |
| 1296@2700 | |
| -622@27000 | |
| Dimensions & Tires | |
| Wheelbase | 70.9 inches 180 cm |
| Weight | 3263 to 3605 pounds |
| Front tire | 8-16 |
| Rear tire | 13.6-24 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| References | |
 | |
| EF300V Series published in 2005, by Yanmar | |
| EF300V Series (0A041-J00501) published in 2009 |
