Yanmar EF328V


No photo available
2005 - 2009
EF300V Series
Compact Utility tractor
EF328
Series:EF326VEF328VEF330V
Production
Manufacturer:Yanmar
Type:Compact Utility tractor
Variants
EF328V:ROPS
EF328VQ:Cab
EF328VJ:ROPS high-speed
EF328VJQ:Cab high-speed
Yanmar EF328V Power
Engine:27.6 hp
20.6 kW
Yanmar EF328V Engine
Yanmar 1.5L 3-cyl diesel
Fuel tank:9.5 gal
36.0 L
Engine details ...
Mechanical
Chassis:4x4 MFWD 4WD
Transmission:16-speed four-speed power shift
Transmission details ...
Photos
No photos of the Yanmar EF328V are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Tractor hitch
Rear Type:JIS1
Rear lift:3307 lbs
1500 kg
Power Take-off (PTO)
Rear PTO:540 (1.375)
Engine RPM:547@2600
755@2600
955@2600
1248@2600
-600@2600
Dimensions & Tires
Wheelbase:64.6 inches
164 cm
Weight:2976 to 3395 pounds
Front tire:7-16
Rear tire:12.4-26
Full dimensions and tires ...
Electrical
Ground:negative
Battery volts:12
