Fendt Farmer 270V


Fendt Farmer 270V tractor photo
1987 - 2002
Farmer 200 Series
Orchard/Vineyard tractor
Series:Farmer 260VFarmer 270VFarmer 280V
207V
Production
Manufacturer:Fendt
Type:Orchard/Vineyard tractor
Fendt Farmer 270V Power
Engine:69.7 hp
52.0 kW
Fendt Farmer 270V Engine
KHD 3.8L 4-cyl diesel
Fuel tank:15.85 gal
60.0 L
Engine details ...
Mechanical
Chassis:4x2 2WD
 4x4 MFWD 4WD
Steering:power
Brakes:mechanical drum
Cab:Two-post mid-mount folding ROPS. Cab available with heat and air-conditioning.
Transmission:20-speed
Transmission details ...
Photos
No photos of the Fendt Farmer 270V are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Pressure:2611 psi
180.0 bar
Total flow:12.4 gpm
46.9 lpm
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:540/750
 540/750/1000*Optional
Dimensions & Tires
2WD Wheelbase:82.9 inches
210 cm
4WD Wheelbase:82.6 inches
209 cm
Weight:5004 to 5159 pounds
Front tire:10.0/75-15.3
Rear tire:9.5-28
Full dimensions and tires ...
Electrical
Ground:negative
Charging system:alternator
Charging amps:55
Charging volts:14
Battery volts:12
Battery AH:88
