Kioti LK3052


No photo available
1993 - 2003
Compact Utility tractor
Production
Manufacturer:Kioti (a part of Daedong)
Type:Compact Utility tractor
Factory:Daegu, South Korea
Variants
LK3052:2WD
LK3054:4WD
Kioti LK3052 Power
Engine (gross):30.5 hp
22.7 kW
PTO (claimed):24.5 hp
18.3 kW
Kioti LK3052 Engine
Daedong 1.4L 3-cyl diesel
Fuel tank:7.5 gal
28.4 L
Engine details ...
Mechanical
Chassis:4x2 2WD
Steering:power
Brakes:wet disc
Cab:Two-post foldable ROPS.
Transmission:8-speed mechanical shuttle
Transmission details ...
Photos
No photos of the Kioti LK3052 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Type:open center
Pump flow:7 gpm
26.5 lpm
Tractor hitch
Rear Type:I
Rear lift (at ends):2150 lbs
975 kg
Power Take-off (PTO)
Rear PTO:live (two-stage clutch)
Rear RPM:540/1000
Front RPM:2600
Dimensions & Tires
Wheelbase:64.6 inches
164 cm
Weight:2866 lbs
1300 kg
Front tire:5.50-16
Rear tire:11.2-24
Full dimensions and tires ...
