Kioti LK3052
|
|
| Production | |
| Manufacturer | Kioti (a part of Daedong) |
| Compact Utility tractor | |
| Built in Daegu, South Korea | |
| Kioti LK3052 Engine | |
| Daedong 1.4L 3-cyl diesel | |
| Fuel tank | 7.5 gal 28.4 L |
 Engine details ... | |
| Kioti LK3052 Transmission | |
| 8-speed synchronized shuttle | |
 Transmission details ... |
| Kioti LK3052 Power | |
| Engine (gross) | 30.5 hp 22.7 kW |
| PTO (claimed) | 24.5 hp 18.3 kW |
| Mechanical | |
| Two-wheel drive | |
| Steering | power |
| Wet disc brakes | |
| Two-post folding ROPS. | |
| Photos | |
 | |
 Kioti LK3052 photos... | |
| Hydraulics | |
| Type | open center |
| Pump flow | 7 gpm 26.5 lpm |
| Tractor hitch | |
| Rear Type | I |
| Rear lift (at ends) | 2150 lbs 975 kg |
| Power Take-off (PTO) | |
| Rear PTO | live (two-stage clutch) |
| Rear PTO Type | 540/1000 |
| Front PTO Type | 2600 |
| Dimensions & Tires | |
| Wheelbase | 64.6 inches 164 cm |
| Weight | 2866 lbs 1300 kg |
| Front tire | 5.50-16 |
| Rear tire | 11.2-24 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| References | |
 | |
| The Leader of the Pack published in 1999, by Kitoi |
