Kubota KL315

No photo available
2008 - 2009   KL Series
Compact Utility tractor
Previous model:Kubota KL300
Series next:Kubota KL345
Series back:Kubota KL285






Production:

Manufacturer:Kubota


Variants:

KL315:standard
KL315H:high-speed


Kubota KL315 Engine:

   Kubota 1.8L 3-cyl diesel
full engine details ...


Capacity:

Fuel:10.6 gal [40.1 L]


3-Point Hitch:

Rear Type:I


Power Take-off (PTO):

Rear RPM:540 (1.375)
Engine RPM:540@2600
762@2600
944@2600
1258@2600
-944@2600


Dimensions & Tires:

Wheelbase:68.7 inches [174 cm]
Weight:2910 to 3384 pounds
Front tire:8-16
Rear tire:12.4-26
full dimensions and tires ...


KL315 Serial Numbers:


how to read serial numbers...



Kubota KL315 Power:

Engine:30.6 hp [22.8 kW]


Mechanical:

Chassis:4x4 MFWD 4WD
Steering:power
Brakes:mechanical wet disc
Cab:Two-post ROPS. Cab optional.


Electrical:

Ground:negative


Battery:

Number:1
Volts:12
