Tractors > Kubota > KL285

Kubota KL285

No photo available
2008 - 2009   KL Series
Compact Utility tractor
Previous model:Kubota KL270
Series next:Kubota KL315
Series back:Kubota KL265






Production:

Manufacturer:Kubota


Variants:

KL285:standard
KL285H:high-speed


Kubota KL285 Engine:

   Kubota 1.6L 3-cyl diesel
full engine details ...


Capacity:

Fuel:9.5 gal [36.0 L]


3-Point Hitch:

Rear Type:I


Power Take-off (PTO):

Rear RPM:540 (1.375)
Engine RPM:561@2700
791@2700
980@2700
1307@2700
-980@2700


Dimensions & Tires:

Wheelbase:67.7 inches [171 cm]
Weight:2833 to 3285 pounds
Front tire:7-16
Rear tire:12.4-24
full dimensions and tires ...


KL285 Serial Numbers:


how to read serial numbers...



Kubota KL285 Power:

Engine:27.6 hp [20.6 kW]


Mechanical:

Chassis:4x4 MFWD 4WD
Steering:power
Brakes:mechanical wet disc
Cab:Two-post ROPS. Cab optional.


Electrical:

Ground:negative


Battery:

Number:1
Volts:12
