Branson 3520H


No photo available
2014 - 2021
Compact Utility tractor
Series map:
3520H
35.0hp
Production
ManufacturerBranson
Compact Utility tractor
Branson 3520H Engine
Kukje 1.7L 3-cyl diesel
Fuel tank9.3 gal
35.2 L
Engine details ...
Branson 3520H Power
Engine35 hp
26.1 kW
PTO (claimed)29 hp
21.6 kW
Mechanical
Four-wheel drive
Power steering
Two-post folding ROPS.
Photos
No photos of the Branson 3520H are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Pump flow8.9 gpm
33.7 lpm
Steering flow4.8 gpm
18.2 lpm
Tractor hitch
Rear TypeI
Controlposition control
Rear lift3306 lbs
1499 kg
Rear Armstelescopic lower links and stabilizers
Power Take-off (PTO)
Rear PTOindependent
Rear RPM540/790
Dimensions & Tires
Wheelbase70.9 inches
180 cm
Weight4053 lbs
1838 kg
Front tire7.5x16
Rear tire12.4x28
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Battery volts12
References
3520H references literature
20 Series Tractors published in 2015, by Branson
20 Series Tractors published in 2018, by Branson
