CaseIH Optum 300
|
|
| Production | |
| Manufacturer | CaseIH |
| Row-Crop tractor | |
| Built in St. Valentin, Austria | |
| Original price was $283,215 in 2016 | |
| CaseIH Optum 300 Engine | |
| FPT 6.7L 6-cyl diesel | |
| Fuel tank | 166 gal 628.3 L |
| Exhaust fluid (DEF) | 25.4 gal 96.1 L |
 Engine details ... | |
| CaseIH Optum 300 Transmission | |
| continuously variable transmission (CVT) | |
 Transmission details ... |
| CaseIH Optum 300 Power | |
| Engine (gross) | 300 hp 223.7 kW |
| Engine (max) | 313 hp 233.4 kW |
| PTO (claimed) | 270 hp 201.3 kW |
| Drawbar (tested) | 226.5 hp 168.9 kW |
| PTO (tested) | 290.7 hp 216.8 kW |
 Performance test details ... | |
| Mechanical | |
| Four-wheel drive | |
| Final drives | inboard planetary |
| Power steering | |
| Wet disc brakes | |
| Trailer brakes | hydraulic |
| SurroundVision cab standard with air-conditioning. AccuGuide | |
| Photos | |
 | |
 CaseIH Optum 300 photos... | |
| Hydraulics | |
| Type | closed center pressure flow compensating (PFC) |
| Rear valves | 4 or 5 |
| Mid valves | 1 or 3 |
| Pump flow | 43.6 gpm 165.0 lpm |
| 58 gpmOptOptional 219.5 lpm | |
| SCV flow | 37 gpm 140.0 lpm |
| Tractor hitch | |
| Rear Type | III |
| IVN OptOptional | |
| Control | electronic draft control |
| Rear lift (at 24"/610mm) | 19180 lbs 8700 kg |
| Rear Arms | telescopic link ends |
| Front lift | 9700 lbs 4399 kg |
| Drawbar | Cat. 3 |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540/540E/1000/1000E (1.375) |
| 1000/1000E (1.75)OptOptional | |
| Front PTO | independent OptOptional |
| Front PTO Type | 1000/1000E (1.375) |
| Dimensions & Tires | |
| Wheelbase | 117.3 inches 297 cm |
| Weight | 23149 lbs 10500 kg |
| Front tire | 420/85R24 |
| Rear tire | 480/80R50 |
 Full dimensions and tires ... | |
| Electrical | |
| Charging system | alternator |
| Charging amps | 150 |
| 200 OptOptional | |
| Battery volts | 12 |
| References | |
 | |
| Optum Series Tractor Specifications published in 2015, by CaseIH |
