Kubota M6-141


Kubota M6-141 tractor photo
2015 -
M6 Series
Utility tractor
Series map:
M6-131
M6-141
131.6hp
141.4hp
Production
ManufacturerKubota
Utility tractor
Kubota M6-141 Engine
Kubota 6.1L 4-cyl diesel
Fuel tank50.2 gal
190.0 L
Exhaust fluid (DEF)5.3 gal
20.1 L
Engine details ...
Kubota M6-141 Transmissions
24-speed partial power shift
32-speed partial power shift
Transmission details ...
Kubota M6-141 Power
Engine (gross)141.4 hp
105.4 kW
Engine (net)133 hp
99.2 kW
PTO (claimed)114 hp
85.0 kW
Drawbar (tested)106.08 hp
79.1 kW
PTO (tested)126.58 hp
94.4 kW
Performance test details ...
Mechanical
Four-wheel drive
Differential lockelectro-hydraulic front and rear
Power steering
Hydraulic wet disc brakes
Grand X Cab standard with air-condiitoning.
Photos
No photos of the Kubota M6-141 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Valves2 to 4
Pump flow20.4 gpm
77.2 lpm
Steering flow14.5 gpm
54.9 lpm
 17 gpm*With optional front axle suspension.
64.3 lpm
Tractor hitch
Rear TypeII
Controlelectronic lower-link draft sensing
Rear lift (at 24"/610mm)6834 lbs
3099 kg
 9447 lbs*Optional, advertised capacity. Tested lift was 8613 pounds.
4285 kg
Rear Armstelescopic lower link ends and stabilizers
Power Take-off (PTO)
Rear PTOindependent
Clutchhydraulic wet disc
Rear RPM540/1000
Dimensions & Tires
Wheelbase105.9 inches
268 cm
 105.5 inches*With optional front axle suspension.
267 cm
Weight10880 to 11321 pounds
Front tire14.9R24
Rear tire18.4R38
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Charging amps130
Battery volts12
References
M6-141 references literature
M6-101/M6-111/M6-131/M6-141 published in 2014, by Kubota
M6-101/M6-111/M6-131/M6-141 published in 2021, by Kubota
