McCormick Intl CX90
|
|
| Production | |
| Manufacturer | McCormick Intl (a part of Argo) |
| Utility tractor | |
| Built in Doncaster, England | |
| McCormick Intl CX90 Engine | |
| Perkins 4.0L 4-cyl diesel | |
| Fuel tank | 41 gal 155.2 L |
 Engine details ... | |
| McCormick Intl CX90 Transmissions | |
| 16-speed two-speed power shift | |
| 24-speed creeper | |
 Transmission details ... |
| McCormick Intl CX90 Power | |
| Engine | 90 hp 67.1 kW |
| Mechanical | |
| Two- or four-wheel drive | |
| Power steering | |
| Wet disc brakes | |
| Two-post folding ROPS. Cab available. |
| Photos | |
| No photos of the McCormick Intl CX90 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | open center |
| SCV flow | 15.85 gpm 60.0 lpm |
| Tractor hitch | |
| Rear Type | II |
| Rear lift | 8543 lbs 3875 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | hydraulic wet disc |
| Rear PTO Type | 540/1000 (1.375) |
| Engine RPM | 540@2000 |
| 1000@2000 | |
| Dimensions & Tires | |
| 2WD Wheelbase | 88.1 inches 223 cm |
| 4WD Wheelbase | 92.8 inches 235 cm |
| Weight | 7397 to 8466 pounds |
| Front tire | 10.00-16 |
| 2WD Rear tire | 16.9R34 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| References | |
 | |
| CX Series published in 2000, by McCormick |
