McCormick Intl X1.35
| Production |
| Manufacturer: | McCormick Intl (a part of Argo)
|
| McCormick Intl X1.35 Power |
| Engine: | 35 hp
26.1 kW
|
| PTO (claimed): | 29 hp
21.6 kW
|
| Mechanical |
| Chassis: | 4x4 MFWD 4WD
|
| Differential lock: | mechanical rear
|
| Steering: | power
|
| Brakes: | wet disc
|
| Cab: | Two-post folding ROPS.
|
| Transmission: | 12-speed synchronized shuttle
|
 Transmission details ... |
| Photos |
| No photos of the McCormick Intl X1.35 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Type: | open center
|
| Valves: | 2*Optional
|
| SCV flow: | 8.9 gpm
33.7 lpm
|
| Tractor hitch |
| Rear Type: | I
|
| Rear lift (at ends): | 3306 lbs
1499 kg
|
| Rear lift (at 24"/610mm): | 2425 lbs
1099 kg
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 540/540E
|
| Electrical |
| Ground: | negative
|
| Battery volts: | 12
|
| Page information |
| Last update: | June 18, 2015
|
| Copyright: | Copyright 2021 TractorData LLC
|
| Contact: | Peter@TractorData.com
|
©2000-2021 - TractorData.com®. Notice: Every attempt is made to ensure the data listed
is accurate. However, differences between sources, incomplete listings,
errors, and data entry mistakes do occur.
Consult official
literature from the manufacturer before attempting any service or repair.
