John Deere 9520RT


John Deere 9520RT tractor photo
2015 -
9R Series
Agricultural Crawler tractor
Series map:
9470RT
9520RT
9570RT
470.0hp
520.0hp
570.0hp
Production
ManufacturerJohn Deere
Agricultural Crawler tractor
Built in Waterloo, Iowa, USA
Variants
9520Rwheeled 4WD
9520RTcrawler
9520RXarticulated crawler
John Deere 9520RT Engine
John Deere 13.5L 6-cyl diesel
Engine details ...
John Deere 9520RT Power
Engine (gross)520 hp
387.8 kW
Engine (max)572 hp
426.5 kW
PTO (claimed)329 hp
245.3 kW
Mechanical
Drivecrawler
Power steering
Hydraulic wet disc brakes
Trailer brakeshydraulic OptOptional
Command View Cab III standard with air-conditioning. AutoTrac ready; ISOBUS 11783; JDLink ready
Capacity
Fuel350 gal
1324.8 L
Exhaust fluid (DEF)22 gal
83.3 L
Hydraulic system79.3 gal
300.2 L
 81.3 gal*With hitch and PTO
307.7 L
Hydraulics
Typeclosed-center pressure/flow compensated
Capacity79.3 gal
300.2 L
 81.3 gal*With hitch and PTO
307.7 L
Pressure2900 psi
200.0 bar
Rear valves4 to 8
Pump flow58 gpm
219.5 lpm
 115 gpm*Optional, with second 57GPM pump
435.3 lpm
SCV flow35 gpm
132.5 lpm
 42 gpm*Flow at 19.1mm coupler with high-flow hydraulic option.
159.0 lpm
Tractor hitch
Rear TypeIV/IVN OptOptional
Rear lift15000 lbs
6804 kg
 20000 lbs
9072 kg
DrawbarCat. 5 HD
Power Take-off (PTO)
Rear PTOindependent OptOptional
Clutchelectro-hydraulic
Rear RPM1000 (1.75)
Dimensions & Tracks
Weight44910 lbs
20371 kg
30-inch tracks
Full dimensions and tracks ...
Electrical
Groundnegative
Charging systemalternator
Batteries3
Battery CCA925
Battery volts12
