Tractors > McCormick Intl > X7.460

McCormick Intl X7.460

McCormick Intl X7.460 tractor photo
2013 -    X7.4 Series
Row-Crop tractor
Series back:McCormick Intl X7.450






Production:

Manufacturer:Argo


McCormick Intl X7.460 Engine:

   BetaPower 4.5L 4-cyl diesel
full engine details ...


Capacity:

Fuel:74 gal [280.1 L]
Exhaust fluid (DEF):10 gal [37.9 L]


3-Point Hitch:

Rear Type:III/IIIN
Control:lower link draft sensing
Rear lift:20500 lbs [9298 kg]
Front Hitch:optional
Front lift:7716 lbs [3499 kg]


Power Take-off (PTO):

Rear PTO:independent
Clutch:electro-hydraulic wet discs
Rear RPM:540/540E/1000/1000E (1.375)
Front PTO:independent (optional)


Dimensions & Tires:

Wheelbase:102.4 inches [260 cm]
Weight:12680 lbs [5751 kg]
Front tire:540/65R28
Rear tire:650/65R38
full dimensions and tires ...


X7.460 Serial Numbers:


- Serial numbers unknown -



McCormick Intl X7.460 Power:

Engine:160 hp [119.3 kW]


Mechanical:

Chassis:4x4 MFWD 4WD
Differential lock:electro-hydraulic front and rear
Steering:hydrostatic power
Brakes:wet disc
Trailer brakes:hydraulic (optional)
 pneumatic (optional)
Cab:Cab standard with air-conditioning. Optional electro-hydraulic cab suspension.


Hydraulics:

Type:closed center
Valves:3 to 6
Pump flow:32.5 gpm [123.0 lpm]
Steering flow:11.6 gpm [43.9 lpm]


Electrical:

Ground:negative


Battery:

Volts:12
