LS XR4040H


LS XR4040H tractor photo
2013 - 2018
XR Series
Compact Utility tractor
Series:XR3037HXR4040HXR4046H
Production
Manufacturer:LS
Type:Compact Utility tractor
LS XR4040H Power
Engine (gross):40 hp
29.8 kW
PTO (claimed):30.8 hp
23.0 kW
LS XR4040H Engine
Shibarua 2.2L 4-cyl diesel
Fuel tank:10.5 gal
39.7 L (ROPS)
 12.4 gal
46.9 L (Cab)
Engine details ...
Mechanical
Chassis:4x4 MFWD 4WD
Steering:hydrostatic power
Brakes:wet disc
Cab:Two-post foldable ROPS. Cab optional with air-conditioning.
Transmission:hydrostatic
Transmission details ...
Photos
No photos of the LS XR4040H are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Pump flow:8.2 gpm
31.0 lpm
Total flow:13.7 gpm
51.9 lpm
Steering flow:5.5 gpm
20.8 lpm
Tractor hitch
Rear Type:I
Control:position and draft control
Rear lift:2756 lbs
1250 kg
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:540 (1.375)
Mid PTO:independent (optional)
Mid RPM:2000
Dimensions & Tires
Wheelbase:69.4 inches
176 cm
Weight:3870 to 4330 pounds
Front tire:9.5-16
Rear tire:13.6-24
Full dimensions and tires ...
Electrical
Ground:negative
Charging system:alternator
Charging amps:85
Battery volts:12
