CaseIH Farmall 75N
| | 2009 - 2016 |
| Farmall N Series | | Orchard/Vineyard tractor |
|
| Production |
| Manufacturer: | CaseIH
|
| Type: | Orchard/Vineyard tractor
|
| Original price: | $41,624 (2014 ROPS )
|
| CaseIH Farmall 75N Power |
| Engine (gross): | 76 hp
56.7 kW
|
| PTO (claimed): | 62 hp
46.2 kW
|
| Mechanical |
| Chassis: | 4x2 2WD
|
| | 4x4 MFWD 4WD
|
| Final drives: | inboard planetary
|
| Differential lock: | mechanical (2WD)
|
| | electro-hydraulic (4WD)
|
| Steering: | hydrostatic power
|
| Brakes: | hydraulic wet disc
|
| Cab: | Two-post foldable mid ROPS. Cab optional with air-conditioning.
|
| Transmissions: | 16-speed mechanical shuttle
|
| | 16-speed power shuttle
|
| | 32-speed power shuttle
|
 Transmission details ... |
| Photos |
| No photos of the CaseIH Farmall 75N are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Type: | open center
|
| Rear valves: | 2 or 3
|
| Pump flow: | 12.7 gpm
48.1 lpm
|
| | 16.9 gpm
64.0 lpm (optional)
|
| Total flow: | 20 gpm
75.7 lpm
|
| Steering flow: | 7.2 gpm
27.3 lpm
|
| Tractor hitch |
| Rear Type: | II
|
| Control: | lower link draft sensing
|
| Rear lift (at 24"/610mm): | 4400 lbs
1995 kg
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Clutch: | hydraulic dry disc
|
| Rear RPM: | 540
|
| | 540/1000
|
| Electrical |
| Ground: | negative
|
| Charging system: | alternator
|
| Charging amps: | 120
|
| Battery CCA: | 800
|
| Battery volts: | 12
|
