Challenger MT565D Tests
|
|
| Tractor Tests | |
| OECD 2704: diesel Techstar CVT 4WD | |
| OECD 2756: diesel AutoPower VI 4WD |
| OCED Tractor Test 2704 | |||
| |||
| OCED Tractor Test 2704 | |
| Diesel Techstar CVT 4WD January 2012 - March 2012, Link: OCED Tractor Test 2704 file | |
| PTO performance | |
| Max power | 183.2 hp 136.6 kW |
| Fuel use | 9.9 gal/hour 37.5 l/hour |
| Power at rated engine speed | 162.3 hp 121.0 kW |
| Fuel use | 9.3 gal/hour 35.2 l/hour |
| Power at rated PTO speed | 169.1 hp 126.1 kW |
| Fuel use | 9.6 gal/hour 36.3 l/hour |
| Drawbar performance | |
| Max power | 124.4 hp 92.8 kW |
| Fuel use | 8.5 gal/hour 32.2 l/hour |
| Pull at 7.44 KPH | |
| Max pull | 16995 lbs 7708 kg |
| Pull at 2.63 KPH | |
| OCED Tractor Test 2756 | |||
| |||
| OCED Tractor Test 2756 | |
| Diesel AutoPower VI 4WD September 2012 - October 2012, Link: OCED Tractor Test 2756 file | |
| PTO performance | |
| Max power | 178.6 hp 133.2 kW |
| Fuel use | 9.8 gal/hour 37.1 l/hour |
| Power at rated engine speed | 156.8 hp 116.9 kW |
| Fuel use | 9.2 gal/hour 34.8 l/hour |
| Power at rated PTO speed | 171.5 hp 127.9 kW |
| Fuel use | 9.6 gal/hour 36.3 l/hour |
| Drawbar performance | |
| Max power | 137.2 hp 102.3 kW |
| Fuel use | 8.6 gal/hour 32.6 l/hour |
| Gear 3A used for power test. | |
| Max pull | 15310 lbs 6944 kg |
| Gear 1F used for pull test. | |
