Challenger MT575D Tests
|
|
| Tractor Tests | |
| OECD 2705: 6.6L diesel Techstar CVT 4WD | |
| OECD 2104A: diesel AutoPower VI 4WD |
| OCED Tractor Test 2705 | |||
| |||
| OCED Tractor Test 2705 | |
| 6.6L diesel Techstar CVT 4WD January 2012 - March 2012, Link: OCED Tractor Test 2705 file | |
| PTO performance | |
| Max power | 202.4 hp 150.9 kW |
| Fuel use | 10.8 gal/hour 40.9 l/hour |
| Power at rated engine speed | 176.7 hp 131.8 kW |
| Fuel use | 10.2 gal/hour 38.6 l/hour |
| Power at rated PTO speed | 187.5 hp 139.8 kW |
| Fuel use | 10.5 gal/hour 39.7 l/hour |
| Drawbar performance | |
| Max power | 135.2 hp 100.8 kW |
| Fuel use | 9.6 gal/hour 36.3 l/hour |
| Pull at 8.62 KPH | |
| Max pull | 17040 lbs 7729 kg |
| Pull at 4.00 KPH | |
| OCED Tractor Test 2104A | |||
| |||
| OCED Tractor Test 2104A | |
| Diesel AutoPower VI 4WD November 18 - December 3, 2014 Link: OCED Tractor Test 2104A file | |
| PTO performance | |
| Max power | 202.14 hp 150.7 kW |
| Fuel use | 11.3 gal/hour 42.8 l/hour |
| Power at rated engine speed | 185.13 hp 138.1 kW |
| Fuel use | 11.2 gal/hour 42.4 l/hour |
| Power at rated PTO speed | 196.82 hp 146.8 kW |
| Fuel use | 11.2 gal/hour 42.4 l/hour |
| Drawbar performance | |
| Max power | 168.77 hp 125.9 kW |
| Fuel use | 11.1 gal/hour 42.0 l/hour |
| Gear 3A used for power test. | |
| Max pull | 16822 lbs 7630 kg |
| Gear 2B used for pull test. | |
