Challenger MT685D


Challenger MT685D tractor photo
2011 - 2013
MT600D Series
Row-Crop tractor
Series map:
MT675D
MT685D
320.0hp
340.0hp
Production
ManufacturerChallenger (a part of AGCO)
Row-Crop tractor
Built in Jackson, Minnesota, USA
Original price was $335,497 in 2014
Variants
8690similar Massey Ferguson model
Challenger MT685D Engine
AGCO Power 8.4L 6-cyl diesel
Engine details ...
Challenger MT685D Power
Engine (gross)340 hp
253.5 kW
PTO (claimed)290 hp
216.3 kW
Drawbar (tested)245.7 hp
183.2 kW
PTO (tested)333.2 hp
248.5 kW
Performance test details ...
Mechanical
Four-wheel drive
Final drivesinboard planetary
Differential lockelectro-hydraulic
Steeringhydrostatic power
Hydraulic wet disc brakes
Trailer brakespneumatic (optional)
 hydraulic (optional)
Cab standard with air-conditioning and OptiRide Plus hydraulic suspension AGCO System 150 (optional); AGCOMMAND (optional)
Photos
No photos of the Challenger MT685D are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel167 gal
632.1 L
Exhaust fluid (DEF)16 gal
60.6 L
Hydraulic system29.1 gal
110.1 L
Hydraulics
Typeclosed center load sensing (CCLS)
Capacity29.1 gal
110.1 L
Pressure2900 psi
200.0 bar
Valves4 to 6
SCV flow26.4 gpm
99.9 lpm
Total flow46 gpm
174.1 lpm
Tractor hitch
Rear TypeCat III
Rear lift22760 lbs
10323 kg
Front HitchCat III (optional)
Front lift (at ends)11000 lbs
4989 kg
DrawbarCat. 3
 Cat. 3 Heavy-Duty (optional)
 Cat. 4 (optional)
Power Take-off (PTO)
Rear PTOindependent
Clutchelectro-hydraulic
Rear RPM1000/1000E (1.75)
 540E/1000/1000E (optional)
Engine RPM540E@1577
1000E@1605
1000@1970
Dimensions & Tires
Wheelbase122 inches
309 cm
Weight24250 lbs
10999 kg
Front tire480/70R34
Rear tire520/85R46
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Charging amps240
Batteries2
Battery volts12
References
MT685D references literature
Challenger MT600D Series published in 2011, by AGCO
