Massey Ferguson 1739E
| | 2013 - |
| 1700 Series | | Compact Utility tractor |
|
| Production |
| Manufacturer: | Massey Ferguson (a part of AGCO)
|
| Type: | Compact Utility tractor
|
| Massey Ferguson 1739E Power |
| Engine: | 39.5 hp
29.5 kW
|
| PTO (claimed): | 32.8 hp
24.5 kW (gear)
|
| | 30.9 hp
23.0 kW (hydro)
|
| Mechanical |
| Chassis: | 4x4 MFWD 4WD
|
| Final drives: | bull gear
|
| Differential lock: | rear standard
|
| Steering: | hydrostatic power
|
| Brakes: | wet disc
|
| Cab: | Two-post folding ROPS.
|
| Transmissions: | 9-speed gear
|
| | hydrostatic
|
 Transmission details ... |
| Hydraulics |
| Type: | open center gear pump
|
| SCV flow: | 7.2 gpm
27.3 lpm
|
| Total flow: | 11.3 gpm
42.8 lpm
|
| Steering flow: | 4.1 gpm
15.5 lpm
|
| Tractor hitch |
| Rear Type: | I
|
| Rear lift (at ends): | 2205 lbs
1000 kg
|
| Rear lift (at 24"/610mm): | 1598 lbs
724 kg
|
| Power Take-off (PTO) |
| Rear PTO: | live
|
| Clutch: | over-running
|
| Rear RPM: | 540 (1.375)
|
| Engine RPM: | 540@2455
|
| Electrical |
| Ground: | negative
|
| Battery volts: | 12
|
| Page information |
| Last update: | January 25, 2019
|
| Copyright: | Copyright 2021 TractorData LLC
|
| Contact: | Peter@TractorData.com
|
©2000-2021 - TractorData.com®. Notice: Every attempt is made to ensure the data listed
is accurate. However, differences between sources, incomplete listings,
errors, and data entry mistakes do occur.
Consult official
literature from the manufacturer before attempting any service or repair.
