Massey Ferguson 1742
| | 2013 - 2018 |
| 1700 Series | | Compact Utility tractor |
|
Series map:
1736
1742
1749
36.2hp
41.6hp
48.3hp
| Production |
| Manufacturer | Massey Ferguson (a part of AGCO)
|
| Compact Utility tractor |
| Original price was $26,318 in 2018 with shuttle, ROPS |
| Massey Ferguson 1742 Power |
| Engine | 41.6 hp
31.0 kW
|
| PTO (claimed) | 32.8 hp
24.5 kW
|
| Mechanical |
| Four-wheel drive |
| Final drives | bull gear
|
| Differential lock | mechanical rear
|
| Power steering |
| Wet disc brakes |
| Two-post folding ROPS. Cab optional with air-conditioning. |
| Hydraulics |
| Type | open center
|
| Valves | 1 to 3
|
| SCV flow | 11.6 gpm
43.9 lpm
|
| Steering flow | 6.8 gpm
25.7 lpm
|
| Tractor hitch |
| Rear Type | I
|
| Control | position control
|
| | draft control OptOptional
|
| Rear lift (at 24"/610mm) | 2535 lbs
1149 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Clutch | electro-hydraulic
|
| Rear PTO Type | 540 (1.375)
|
| Mid PTO | independent OptOptional
|
| Mid PTO Type | 2000
|
| Electrical |
| Ground | negative
|
| Battery volts | 12
|
| References |
 |
| New 1700 Series Premium Compacts published in 2013, by Massey Ferguson |
| 1700 Series published in 2016, by Massey Ferguson |
| Page information |
 |
| Copyright 2026 TractorData.com® |
| Email me: Peter@TractorData.com |
| TractorData is a family-owned small business located in Minnesota. I have been researching tractor history and providing specifications for free since 1999. |
| Peter Easterlund - owner/author |
| This machine's data modified on August 17, 2026 |
