Massey Ferguson 1742


Massey Ferguson 1742 tractor photo
2013 - 2018
1700 Series
Compact Utility tractor
1643
Series:173617421749
Production
Manufacturer:Massey Ferguson
Type:Compact Utility tractor
Original price:$26,318 (2018 shuttle ROPS )
Massey Ferguson 1742 Power
Engine:41.6 hp
31.0 kW
PTO (claimed):32.8 hp
24.5 kW
Massey Ferguson 1742 Engine
Mitsubishi 1.7L 3-cyl diesel
Fuel tank:14.5 gal
54.9 L
Engine details ...
Mechanical
Chassis:4x4 MFWD 4WD
Final drives:bull gear
Brakes:wet disc
Cab:Two-post folding ROPS. Cab optional with air-conditioning.
Transmissions:12-speed power shuttle
 hydrostatic
Transmission details ...
Hydraulics
Type:open center gear pump
Valves:1 to 3
SCV flow:11.6 gpm
43.9 lpm
Tractor hitch
Rear Type:I
Control:position control
 draft control*Optional
Rear lift (at 24"/610mm):2535 lbs
1149 kg
Power Take-off (PTO)
Rear PTO:independent
Clutch:electro-hydraulic
Rear RPM:540 (1.375)
Mid PTO:optional
Mid RPM:2000
Dimensions & Tires
Wheelbase:71.1 inches
180 cm
Weight:3638 to 4068 pounds
Full dimensions and tires ...
Electrical
Ground:negative
Battery volts:12
