CaseIH Steiger 370
| | 2014 - 2023 |
| Steiger 4WD Series | | Four-wheel Drive (4WD) tractor |
|
| Production |
| Manufacturer | CaseIH (a part of CNH)
|
| Four-wheel Drive (4WD) tractor |
| Built in Fargo, North Dakota, USA |
| Original price was $314,043 in 2015 |
| Variants |
| 370 | wheeled tractor
|
| 370RT | crawler tractor
|
| T9.435 | similar New Holland model
|
| CaseIH Steiger 370 Power |
| Engine | 370 hp
275.9 kW
|
| PTO (claimed) | 311 hp
231.9 kW
|
| Drawbar (tested) | 300.99 hp
224.4 kW
|
| PTO (tested) | 366.46 hp
273.3 kW
|
 Performance test details ... |
| Mechanical |
| Four-wheel drive |
| Final drives | inboard planetary
|
| Steering | hydraulic articulated
|
| Hydraulic wet disc brakes |
| Trailer brakes | hydraulic OptOptional
|
| Surveyor Cab standard with air-conditioning. |
| Photos |
| No photos of the CaseIH Steiger 370 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Capacity |
| Fuel | 220 gal
832.7 L
|
| Exhaust fluid (DEF) | 42 gal
159.0 L
|
| Hydraulic system | 62.5 gal
236.6 L
|
| Hydraulics |
| Type | closed center load sensing
|
| Capacity | 62.5 gal
236.6 L
|
| Valves | 4 to 8
|
| Pump flow | 40 gpm
151.4 lpm
|
| | 55 gpm*High Flow option
208.2 lpm
|
| | 108 gpm*TwinFlow option
408.8 lpm
|
| SCV flow | 35 gpm
132.5 lpm
|
| Tractor hitch |
| Rear Type | IVN
|
| | III *Optional.
|
| Rear lift (at 24"/610mm) | 20000 lbs
9072 kg
|
| Rear Arms | quick coupler
|
| Drawbar | Cat. 4
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Rear PTO Type | 1000 (1.75)
|
| Engine RPM | 1000@1998 (early)
|
| | 1000@1811 (late)
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 200
|
| Batteries | 2
|
| Battery CCA | 1000
|
| Battery volts | 12
|
| References |
 |
| Steiger 370-620 Tractors published in 2014, by CaseIH |
| Page information |
 |
| Copyright 2024 TractorData.com® |
| TractorData is a family-owned small business located in Minnesota that has been providing reference information on tractors since 1999. |
| Peter Easterlund - owner/author |
| Email: Peter@TractorData.com |
| Updated on December 10, 2024 |
©2000-2024 - TractorData.com®. Notice: Every attempt is made to ensure the data listed
is accurate. However, differences between sources, incomplete listings,
errors, and data entry mistakes do occur.
Consult official
literature from the manufacturer before attempting any service or repair.
Engine details ...
Transmission details ...
Full dimensions and tires ...
