Tractors > CaseIH > Steiger 350 Rowtrac

CaseIH Steiger 350 Rowtrac

CaseIH Steiger 350 Rowtrac tractor photo
2013 - 2013   Steiger Rowtrac Series
Agricultural Crawler tractor
Series next:CaseIH Steiger 400 Rowtrac






Production:

Manufacturer:CaseIH
Factory:Fargo, North Dakota, USA
Original price (USD)
   $344,973 (2013 )


CaseIH Steiger 350 Rowtrac Engine:

   FPT 8.7L 6-cyl diesel
full engine details ...


Capacity:

Fuel:250 gal [946.3 L]
Exhaust fluid (DEF):46 gal [174.1 L]


Drawbar:

Drawbar:Category 4, Swinging


3-Point Hitch:

Rear Type:IVN
 IIIN*Optional
Control:lower link draft sensing
Rear lift (at 24"/610mm):20000 lbs [9072 kg]
Rear Arms:fixed


Power Take-off (PTO):

Rear PTO:independent
Rear RPM:1000 (1.375)


Dimensions & Tires:

Wheelbase:160 inches [406 cm]
Weight:50800 to 51905 pounds
Front tire:tracks
Rear tire:tracks
full dimensions and tires ...


Steiger 350 Rowtrac Serial Numbers:


- Serial numbers unknown -



CaseIH Steiger 350 Rowtrac Power:

Engine:350 hp [261.0 kW]
PTO (claimed):290 hp [216.3 kW]
Drawbar (tested):261.07 hp [194.7 kW]
PTO (tested):346.42 hp [258.3 kW]
power test details ...


Mechanical:

Chassis:articulated crawler
Final drives:inboard planetary
Brakes:wet disc
Cab:Surveyor Cab standard with air-conditioning.


Hydraulics:

Type:pressure flow compensated
Rear valves:4 to 8
 5*With 3-point hitch.
Pump flow:40 gpm [151.4 lpm]
 55 gpm [208.2 lpm] *Optional
 108 gpm [408.8 lpm] *Optional
SCV flow:35 gpm [132.5 lpm]


Electrical:

Ground:negative
Charging system:alternator
Charging amps:200


Battery:

Volts:12
