McCormick Intl X10.75M


McCormick Intl X10.75M tractor photo
2011 - 2014
X10 Series
Compact Utility tractor
Daedong built
Series:X10.55MX10.75MX10.90M
Production
Distributor:McCormick Intl
Manufacturer:Daedong
Type:Compact Utility tractor
Factory:South Korea
McCormick Intl X10.75M Power
Engine (gross):74.4 hp
55.5 kW
PTO (claimed):58.4 hp
43.5 kW
McCormick Intl X10.75M Engine
Perkins 4.4L 4-cyl diesel
Fuel tank:33 gal
124.9 L
Engine details ...
Mechanical
Chassis:4x4 MFWD 4WD
Differential lock:rear standard
Steering:hydrostatic power
Brakes:wet disc
Cab:Cab standard with air-condioning. Optional rear wiper and CD player.
Transmission:12-speed syncronized shuttle
Transmission details ...
Photos
No photos of the McCormick Intl X10.75M are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Valves:1 to 3
Total flow:22.1 gpm
83.6 lpm
Tractor hitch
Rear Type:II
Control:position and draft control
Rear lift (at 24"/610mm):5,290 lbs
2399 kg
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:540
Dimensions & Tires
Wheelbase:90.7 inches
230 cm
Weight:7,749 lbs
3514 kg
Front tire:11.2x24
Rear tire:16.9x30
Full dimensions and tires ...
Electrical
Ground:negative
Battery
Volts:12
