Massey Ferguson 5455


Massey Ferguson 5455 tractor photo
2005 - 2013
Model year
5400 Series
Utility tractor
Series map:
5450
5455
5460
83.3hp*
105.0hp
115.0hp
Production
ManufacturerMassey Ferguson
Utility tractor
Built in Beauvais, France
Original price$40,114 (2009 ROPS 2WD )
$56,539 (2009 Cab 4WD )
Massey Ferguson 5455 Engine
Perkins 4.4L 4-cyl diesel
Fuel tank38 gal
143.8 L
 50 gal*Total capacity with optional 45 liter tank.
189.3 L
Engine details ...
Massey Ferguson 5455 Power
Engine (gross)105 hp
78.3 kW
PTO (claimed)85 hp
63.4 kW
Drawbar (tested)67.7 hp
50.5 kW
PTO (tested)109.3 hp
81.5 kW
Performance test details ...
Mechanical
Two- or four-wheel drive
Final drivesinboard planetary
Differential lockelectro-hydraulic rear
Power steering
Hydraulic wet disc brakes
Trailer brakeshydraulic *Optionlal
Two-post folding ROPS. Cab optional with air-conditioning.
Hydraulics
Typeopen center
 closed center load-sensing *Optional with cab.
Valves2 to 4
Pump flow15 gpm (open center)
56.8 lpm
 26 gpm (open optional)
98.4 lpm
 29 gpm (closed center)
109.8 lpm
Tractor hitch
Rear TypeII
Controlelectronic draft control
Rear lift (at 24"/610mm)7817 lbs
3545 kg
 9189 lbsOptOptional
4168 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540/1000
Dimensions & Tires
Wheelbase100.5 inches
255 cm
 97 inches (Hi-Vis)
246 cm
Weight9198 to 9848 pounds
Front tire9.5L-15
2WD Rear tire420/85R30
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Charging amps80
Battery CCA775
Battery volts12
References
5455 references literature
5400 Series published in 2010, by Massey Ferguson
MF 5400 published in 2012, by Massey Ferguson
