Tractors > Massey Ferguson > 595
      -Brand search:


    Massey Ferguson 595

    Massey Ferguson 595 tractor photo
    1977 - 1982






    Production:

    Manufacturer:Massey Ferguson


    Massey Ferguson 595 Engine:

       Perkins 5.2L 4-cyl diesel
    full engine details ...


    Capacity:

    Fuel:33.8 gal [127.9 L]


    3-Point Hitch:

    Rear Type:2
    Control:position and draft control with top-link sensing
    Rear lift:5,400 lbs [2449 kg]


    Power Take-off (PTO):

    Rear PTO:independent
    Clutch:hydraulic wet disc
    Rear RPM:540 (1.375)
     1000 (1.375)
    Engine RPM:540@1750
    1000@2000


    Dimensions & Tires:

    Wheelbase:104.3 inches [264 cm] (2WD)
     102.4 inches [260 cm] (4WD)
    Weight:9040 to 9900 pounds
    Front tire:11.00-16
    Rear tire:16.9-38 (2WD)
    full dimensions and tires ...


    595 Serial Numbers:


    - Serial numbers unknown -



    Massey Ferguson 595 Power:

    Engine:108.5 hp [80.9 kW]


    Mechanical:

    Chassis:4x2 2WD
     4x4 MFWD 4WD (optional)
    Final drives:outboard planetary
    Steering:hydrostatic power
    Brakes:wet disc
    Cab:Cab standard.


    Hydraulics:

    Pressure:2400 psi [165.5 bar]
    Pump flow:6.7 gpm [25.4 lpm]
