Tractors > John Deere > 5090G

John Deere 5090G

No photo available
2009 - 2013   5G Series
Utility tractor
Series back:John Deere 5080G






Production:

Distributor:John Deere
Manufacturer:Agritalia
Factory:Rovigo, Italy


Variants:

5090G:utility
5090GH:high-crop
5090GF:orchard
5090GV:vineyard


John Deere 5090G Engine:

   John Deere 4.5L 4-cyl diesel
full engine details ...


Capacity:

Fuel:25.4 gal [96.1 L]


3-Point Hitch:

Rear Type:II/I
Rear lift:5,845 lbs [2651 kg]


Power Take-off (PTO):

Rear RPM:540/540E/ground
 540/1000/ground


Dimensions & Tires:

Wheelbase:86 inches [218 cm]
Weight:6724 to 7055 pounds
full dimensions and tires ...


5090G Serial Numbers:


- Serial numbers unknown -



John Deere 5090G Power:

Engine:90 hp [67.1 kW]


Mechanical:

Chassis:4x2 2WD
 4x4 MFWD 4WD (optional)
Steering:hydrostatic power
Brakes:wet disc
Cab:ROPS (2- or 4-post). Cab optional.


Hydraulics:

Pressure:2700 psi [186.2 bar]
Pump flow:11.9 gpm [45.0 lpm]
 15.6 gpm [59.0 lpm] (optional)
Steering flow:6.5 gpm [24.6 lpm]
Steering press.:1900 psi [131.0 bar]


Electrical:

Ground:negative
Charging system:alternator
Charging amps:45
 95 (cab)


Battery:

Volts:12
Amp-hours:100
