Century 3642
| | Compact Utility tractor | | Kukje built |
|
| Production |
| Distributor: | Century
|
| Manufacturer: | Kukje
|
| Type: | Compact Utility tractor
|
| Factory: | Yangsu-ri, South Korea
|
| Century 3642 Power |
| Engine: | 42 hp
31.3 kW
|
| PTO (claimed): | 36 hp
26.8 kW
|
| Mechanical |
| Chassis: | 4x4 MFWD 4WD
|
| Differential lock: | foot pedal
|
| Steering: | hydrostatic power
|
| Brakes: | differential wet disc
|
| Cab: | ROPS.
|
| Transmission: | 12-speed partially synchronized
|
 Transmission details ... |
| Photos |
| No photos of the Century 3642 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Capacity |
| Fuel: | 11.1 gal
42.0 L
|
| Hydraulic system: | 9.25 gal
35.0 L
|
| Front axle: | 7.4 qts
7.0 L
|
| Hydraulics |
| Type: | open center
|
| Capacity: | 9.25 gal
35.0 L
|
| Valves: | 1 to 3
|
| Pump flow: | 8.9 gpm
33.7 lpm
|
| Total flow: | 13.2 gpm
50.0 lpm
|
| Tractor hitch |
| Rear Type: | I
|
| Rear lift (at ends): | 2,580 lbs
1170 kg
|
| Power Take-off (PTO) |
| Rear PTO: | live (2-stage clutch)
|
| Rear RPM: | 540/1000
|
| 3642 Serial Numbers |
| Location: | Serial number plate on the rear of the tractor, above the drawbar.
|
| Electrical |
| Ground: | negative
|
| Charging amps: | 45
|
| Battery volts: | 12
|
