Production | |
Manufacturer | Massey Ferguson |
Row-Crop tractor | |
Built in Beauvais, France |
Massey Ferguson 7499 Engine | |
AGCO Sisu Power 7.4L 6-cyl diesel | |
Engine details ... |
Massey Ferguson 7499 Transmission | |
continuously variable transmission (CVT) | |
Transmission details ... |
Massey Ferguson 7499 Power | |
Engine | 220 hp 164.1 kW |
PTO (claimed) | 180 hp 134.2 kW |
Drawbar (tested) | 162.36 hp 121.1 kW |
PTO (tested) | 217.30 hp 162.0 kW |
Performance test details ... |
Mechanical | |
Four-wheel drive | |
Final drives | inboard planetary |
Differential lock | electro-hydraulic front and rear |
Power steering | |
Hydraulic wet disc brakes | |
Cab standard with air-conditioning. Pneumatic cab suspension optional. |
Capacity | |
Fuel | 94 gal 355.8 L |
Hydraulic system | 15.3 gal 57.9 L |
Hydraulics | |
Type | closed center |
Capacity | 15.3 gal 57.9 L |
Pressure | 2900 psi 200.0 bar |
Valves | 3 or 4 |
Total flow | 29.1 gpm 110.1 lpm |
  | 39.6 gpm (optional) 149.9 lpm |
Tractor hitch | |
Rear Type | III |
Control | lower-link draft sensing |
Rear lift (at 24"/610mm) | 16140 lbs 7321 kg |
Front Hitch | optional |
Front lift | 8800 lbs 3991 kg |
Power Take-off (PTO) | |
Rear PTO | independent |
Clutch | electro-hydraulic |
Rear RPM | 540/540E/1000 |
Dimensions & Tires | |
Wheelbase | 118 inches 299 cm |
Weight | 16372 to 17685 pounds |
Full dimensions and tires ... |
Electrical | |
Ground | negative |
Charging system | alternator |
Charging amps | 175 |
Batteries | 2 |
Battery CCA | 600 |
Battery volts | 12 |
