New Holland TN75DA
| | 2004 - 2008 |
| TN-A Series | | Utility tractor |
|
| Production |
| Manufacturer: | New Holland
|
| Type: | Utility tractor
|
| Factory: | Jesi, Italy
|
| New Holland TN75DA Power |
| Engine (gross): | 75 hp
55.9 kW
|
| Engine: | 72 hp
53.7 kW
|
| PTO (claimed): | 62 hp
46.2 kW
|
| Drawbar (tested): | 54.0 hp
40.3 kW
|
| PTO (tested): | 64.4 hp
48.0 kW
|
| power test details ... |
| Mechanical |
| Chassis: | 4x2 2WD
|
| | 4x4 MFWD 4WD (optional)
|
| Steering: | hydrostatic power
|
| Brakes: | differential wet disc
|
| Cab: | Cab standard.
|
| Transmissions: | 16-speed partially synchronized with mechanical shuttle
|
| | 16-speed partially synchronized with power shuttle
|
 Transmission details ... |
| Photos |
| No photos of the New Holland TN75DA are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Type: | open center
|
| Pressure: | 2755 psi
190.0 bar
|
| Valves: | 1 to 4
|
| Pump flow: | 16.9 gpm
64.0 lpm
|
| Steering flow: | 7.4 gpm
28.0 lpm
|
| | 9.4 gpm
35.6 lpm (with power shuttle)
|
| Tractor hitch |
| Rear Type: | II/I
|
| Rear lift (at 24"/610mm): | 3,960 lbs
1796 kg
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 540
|
| Electrical |
| Ground: | negative
|
| Charging system: | alternator
|
| Charging amps: | 85
|
| Battery CCA: | 730
|
| Battery volts: | 12
|
