Tractors > CaseIH > Farmall 95

CaseIH Farmall 95

CaseIH Farmall 95 tractor photo
2008 -    Farmall Utility Series
Utility tractor
Previous model:CaseIH JX95
Series back:CaseIH Farmall 90






Production:

Distributor:CaseIH
Manufacturer:Turk Tractor
Factory:Ankara, Turkey


CaseIH Farmall 95 Engine:

   FPT 4.5L 4-cyl diesel
full engine details ...


Capacity:

Fuel:23.8 gal [90.1 L]


3-Point Hitch:

Rear Type:2
Control:position control and mechanical lower-link draft sensing
Rear lift (at 24"/610mm):5,025 lbs [2279 kg]


Power Take-off (PTO):

Rear PTO:independent
Clutch:mechanical dry clutch
Rear RPM:540
 540/1000 (optional)


Dimensions & Tires:

2WD Wheelbase:94 inches [238 cm]
4WD Wheelbase:92 inches [233 cm]
Weight:6107 to 7320 pounds
full dimensions and tires ...


CaseIH Farmall 95 attachments:

 front-end loader
all Farmall 95 attachments ...


Farmall 95 Serial Numbers:


- Serial numbers unknown -



CaseIH Farmall 95 Power:

Engine (gross):90 hp [67.1 kW]
PTO (claimed):80 hp [59.7 kW]
Drawbar (tested):74.4 hp [55.5 kW]
PTO (tested):80.7 hp [60.2 kW]
power test details ...


Mechanical:

Chassis:4x2 2WD
 4x4 MFWD 4WD (optional)
Differential lock:mechanical rear lock
Steering:hydrostatic power
Brakes:hydraulic wet disc
Cab:Flat deck platform with ROPS. Cab optional.


Hydraulics:

Type:open center
Pressure:2755 psi [190.0 bar]
Rear valves:1 to 3
Pump flow:13.6 gpm [51.5 lpm]
Total flow:21.7 gpm [82.1 lpm]
Steering flow:8.1 gpm [30.7 lpm]


Electrical:

Ground:negative
Charging system:alternator
Charging amps:85


Battery:

Number:1
Cold-cranking amps:800
Volts:12
