Tractors > CaseIH > Farmall 80
      -Brand search:


    CaseIH Farmall 80

    CaseIH Farmall 80 tractor photo
    2008 -    Farmall Utility Series
    Utility tractor
    Previous model:CaseIH JX80
    Larger:CaseIH Farmall 90
    Smaller:CaseIH Farmall 70






    Production:

    Distributor:CaseIH
    Manufacturer:Turk Tractor
    Factory:Ankara, Turkey


    CaseIH Farmall 80 Engine:

       FPT 3.9L 4-cyl diesel
    full engine details ...


    Capacity:

    Fuel:23.8 gal [90.1 L]


    3-Point Hitch:

    Rear Type:2
    Control:position control and mechanical lower-link draft sensing
    Rear lift (at 24"/610mm):5,025 lbs [2279 kg]


    Power Take-off (PTO):

    Rear PTO:independent
    Clutch:mechanical dry clutch
    Rear RPM:540


    Dimensions & Tires:

    2WD Wheelbase:91 inches [231 cm]
    4WD Wheelbase:87 inches [220 cm]
    Weight:5702 to 6915 pounds
    full dimensions and tires ...


    CaseIH Farmall 80 attachments:

     front-end loader
    all Farmall 80 attachments ...


    Farmall 80 Serial Numbers:


    - Serial numbers unknown -



    CaseIH Farmall 80 Power:

    Engine (gross):72 hp [53.7 kW]
    PTO (claimed):62 hp [46.2 kW]
    Drawbar (tested):59.7 hp [44.5 kW]
    PTO (tested):72.1 hp [53.8 kW]
    power test details ...


    Mechanical:

    Chassis:4x2 2WD
     4x4 MFWD 4WD (optional)
    Differential lock:mechanical rear lock
    Steering:hydrostatic power
    Brakes:hydraulic wet disc
    Cab:Flat deck platform with ROPS. Cab optional.


    Hydraulics:

    Type:open center
    Rear valves:1 to 3
    Pump flow:13.6 gpm [51.5 lpm]
    Total flow:21.7 gpm [82.1 lpm]
    Steering flow:8.1 gpm [30.7 lpm]


    Electrical:

    Ground:negative
    Charging system:alternator
    Charging amps:85


    Battery:

    Number:1
    Cold-cranking amps:800
    Volts:12
