Challenger MT675C

Challenger MT675C tractor photo
2009 - 2010
MT600C Series
Row-Crop tractor
Series map:
ManufacturerChallenger (a part of AGCO)
Row-Crop tractor
Built in Beauvais, France
Original price was $252,494 in 2009
8680similar Massey Ferguson model
Challenger MT675C Engine
AGCO SISU POWER 8.4L 6-cyl diesel
Fuel tank155.9 gal
590.1 L
 182.3 gal (without SCR)
690.0 L
Exhaust fluid (DEF)7.9 gal
29.9 L
Engine details ...
Challenger MT675C Power
Engine (gross)320 hp
238.6 kW
PTO (claimed)275 hp
205.1 kW
Drawbar (tested)240.7 hp
179.5 kW
PTO (tested)322.6 hp
240.6 kW
Performance test details ...
Four-wheel drive
Final drivesplanetary
Differential lockelectro-hydraulic front and rear
Power steering
Hydraulic wet disc brakes
Cab standard with heat and air-conditioning. Optional heated seat, power adjustable mirrors, and automatic temperature control.
No photos of the Challenger MT675C are currently available. To submit yours, email it to Photos may only be used with the permission of the original photographer.
Typeclosed center load sensing
Pressure2,901 psi
200.0 bar
Valves4 to 6
Pump flow26.4 gpm
99.9 lpm
Total flow46.2 gpm
174.9 lpm
Tractor hitch
Rear TypeIII
Controlelectronic lower-link draft sensing
Rear lift (at ends)26,460 lbs
12002 kg
Rear lift (at 24"/610mm)21,336 lbs
9678 kg
Front lift (at ends)11,020 lbs
4998 kg
Power Take-off (PTO)
Rear PTOindependent
Rear RPM1000E/1000 (1.75)
 540E/1000 (1.375)OptOptional
Front PTOindependent OptOptional
Front RPM1000 (1.375)
Dimensions & Tires
Wheelbase122.2 inches
310 cm
Weight24,250 lbs
10999 kg
Front tire480/70R34
Rear tire520/85R46
Full dimensions and tires ...
MT675C Serial Numbers
MT675C Serial Location
Challenger MT675C serial number location
Serial number plate below the tractor cab door on the right side.
Charging systemalternator
Charging amps240 *Two 120A alternators.
Battery CCA775
Battery volts12
MT675C references literature
Challenger - The New MT600C Series published in 2009, by AGCO
