Tractors > Iseki > TJ75

Iseki TJ75

Iseki TJ75 tractor photo
2003 - 2009   TJ Series
Utility tractor
Series next:Iseki TJ85
Series back:Iseki TJ85






Production:

Manufacturer:Iseki


Variants:

TJ75:wheel tractor
TJ75C:half-track


Iseki TJ75 Engine:

   Iseki 3.0L 4-cyl diesel
full engine details ...


Capacity:

Fuel:23.8 gal [90.1 L]


3-Point Hitch:

Rear Type:JIS1
 JIS2
Rear lift (at ends):5732 lbs [2600 kg]


Power Take-off (PTO):

Rear PTO:independent
Rear RPM:540 (1.375)
Engine RPM:566@2600
733@2600
1061@2600


Dimensions & Tires:

Wheelbase:84.7 inches [215 cm]
Weight:5600 lbs [2540 kg]
Front tire:9.5-22
Rear tire:12.4-36
full dimensions and tires ...


TJ75 Serial Numbers:


how to read serial numbers...



Iseki TJ75 Power:

Engine:74 hp [55.2 kW]


Mechanical:

Chassis:4x2 2WD
 4x4 MFWD 4WD
Differential lock:mechanical rear
Steering:power
Brakes:wet discs
Cab:Cab with air-conditioning.


Hydraulics:

Total flow:7.7 gpm [29.1 lpm]


Electrical:

Ground:negative


Battery:

Number:1
Volts:12
Amp-hours:72
