    Ford 6640

    Ford 6640 tractor photo
    1991 - 1995   PowerStar 40 Series
    Utility tractor
    Previous model:Ford 6610
    Next model:New Holland TS100
    Larger:Ford 7740
    Smaller:Ford 5640






    Production:

    Manufacturer:Ford
    Factory:Basildon, England
    Original price (USD):$33,400 (1998)


    Variants:

    6640S:8-speed economy
    6640SL:12-speed
    6640SLE:16-speed premium


    Ford 6640 Engine:

       Ford 5.0L 4-cyl diesel
    full engine details ...


    Capacity:

    Fuel:25 gal [94.6 L]
     52.7 gal [199.5 L] (ROPS optional)
     46.9 gal [177.5 L] (cab optional)


    3-Point Hitch:

    Rear Type:II
    Control:Position control and top-link draft sensing. Electronic lower-link sensing optional on 6640 SLE.
    Rear lift (at 24"/610mm):4,200 lbs [1905 kg]
     4,439 lbs [2013 kg] (optional)
     6,210 lbs [2816 kg] (SLE)
     6,564 lbs [2977 kg] (SLE optional)


    Power Take-off (PTO):

    Rear PTO:independent
    Rear RPMs:540
     540/1000 (optional)


    Dimensions & Tires:

    Wheelbase:93 inches [236 cm]
    Weight:7099 to 10368 pounds
    Front tire:7.50-16
    Rear tire:16.9-30
    full dimensions and tires ...


    6640 Serial Numbers:

    Location:Data plate inside hood.
    1991: BC68791
    1992: BD02865
    1993: BD35935
    1994: BD65544
    1995: BD98440
    1996: 021630B
    1997: 056502B
    1998: 083503B

    how to read serial numbers...



    Ford 6640 Power:

    PTO (claimed):76 hp [56.7 kW]
    Drawbar (tested):67.18 hp [50.1 kW]
    PTO (tested):77.13 hp [57.5 kW]
    power test details ...


    Mechanical:

    Chassis:4x2 2WD
     4x4 MFWD 4WD (optional)
    Final drives:inboard planetary
    Differential lock:mechanical (S)
     electro-hydraulic (SL/SLE)
    Steering:hydrostatic power
    Brakes:mechanical (S)
     hydraulic wet disc (SL/SLE)
    Cab:Two-post foldable ROPS. Straddle-mount (6640 S) or raised deck (SL/SLE). Comfort Command Cab optional with air-conditioning (SL/SLE).


    Hydraulics:

    Type:open center (S/SL)
     closed center load sensing (SLE)
    Valves:1 to 4
    Pump flow:18.2 gpm [68.9 lpm]
     21 gpm [79.5 lpm] (SLE)
    Steering press.:2100 psi [144.8 bar]


    Electrical:

    Ground:negative
    Charging system:alternator
    Charging amps:55 (ROPS)
     100 (cab)


    Battery:

    Number:1 (ROPS)
     2 (cab)
    Cold-cranking amps:800
    Volts:12
